Model LSX2091B

• 20GHz Single Channel Microwave signal generator
• Frequency Resolution of 0.001Hz
• Phase noise of -134dBc/Hz at 1GHz, and -115dBc/Hz at 10GHz, at 10kHz carrier offset
• Max amplitude 10dBm Calibrated, 15dBm Settable
• Min amplitude -50dBm Calibrated, -70dBm Settable
• Amplitude Resolution of 0.01dB
• AM, FM, PM, Sweep & Pulse Modulation
• USB and LAN interfaces
• Small form factor and space efficient benchtop platform
• Remotely programmable via MATLAB, Python, LabVIEW and other software programming environments.
• Removable SD card for instrument security
• Easy to use benchtop platform with 5" touch screen and user friendly GUI

Easy to use

Tabor’s Lucid series benchtop platform offers a 5” touch screen with user friendly GUI to quickly and easily generate the required signal, while displaying all the necessary critical information to the user. For remote control, the series is equipped with Ethernet and USB interface enabling remote programming from PC.

Signal Integrity and Purity

One of the most important requirements in today’s testing and measurement applications is a high signal quality. With a typical SSB phase noise of -134dBc/Hz at 1GHz, and -115dBc/Hz at 10GHz, at 10 kHz carrier offset, Tabor’s Lucid Series platform delivers great quality signals with the best price to performance value.

Extremely Fast Switching

Time is a crucial factor, whether in design, on the production floor or inside ATE systems. With a switching speed of less than 500 µs (100 µs optional) at up to 20GHz, Tabor’s Lucid Series ensures maximum measurements at minimum time, setting the industry’s highest throughput standard.

Modulation Schemes

Signal bursts and chirps have become common need in most aerospace or defence application. With Tabor’s All-New Lucid Series, any signal modulation is possible, no matter if “narrow” or “standard” signals are required. On top of its outstanding pulse modulation performance, the Lucid Series is also equipped with many CW interferers, and modulated signals such as AM, FM, PM, Pulse, Pattern and Sweep.

Multiple Ways to Control the Unit and Write your Code

Tabor’s Lucid X Series comes with its own dedicated software to control the instrument functions, modes and features via a graphical user interface (GUI) as well as a complete set of drivers, allowing you to write your application in various environments including LabVIEW, Python, CVI, C++, VB and MATLAB. You may also link the supplied dll to other Windows-based API’s or use low-level SCPI commands to program the instrument, regardless of whether your application is written for Windows, Linux or Macintosh operating systems.

Options

Accessories

Note: Options and Accessories must be specified at the time of your purchase.
