Taborelec | Aerospace & Defense - waveform generation and radar test

The design of aerospace and defense technology requires uncompromising high-precision instrumentation. Radar, radio monitoring, and satellite systems need to adhere to strict standards and achieve high-performance results.

Our products allow aerospace engineers to perform real-time data streaming and fast feedback loops with an environment-dependent arbitrary waveform generation. Or to test a radar with an RF signal generator, which in turn must meet tough specifications.

Links

Videos

Radar Measurement, Part 1 – Measuring Distance

Direct to/from Microwave RADAR Signal Generation, Acquisition, and Analysis – Demo.

Solution notes

Proteus Radar Target Simulator

This document describes how to implement a Radar Target Simulator/Generator using the Tabor Electronics’ Proteus AWT (Arbitrary Waveform Transceiver). The Proteus AWT RTS system is a configuration of the Proteus AWT that is design to receives a signal from the Radar under test and performs real time calculations in its internal FPGA to simulate a moving target.

Proteus Radar Target Simulator Solution Note (1349KB)

Proteus AWT, Radar Primer

A radar transmitter generates multiple forms of electromagnetic energy. This energy is amplified and transmitted and ultimately is reflected off a target, received and the difference in time and frequency of the transmit signal verses the received signal is used to determine the distance and velocity of a target.

Solution Note - Proteus AWT, Radar Primer (1333KB)

Radar Signal Simulation using an AWG

RADAR (“Radio Detection And Ranging”) is a system that uses electromagnetic waves to identify the range, altitude, direction, or speed of both moving and fixed objects such as aircraft, ships, motor vehicles, weather formations, and terrain. Radar systems use transmitters that emit electromagnetic waves that are reflected by a target (“echoes”) and detected by a receiver.

Download Solution note (1078KB)

Related Products

Different Types of Signal Generators

A quick look at some of the most common signal generators used to produce waveforms, frequencies, radio frequencies (RF), digital patterns, etc.

Advanced Microwave Topics for Quantum Physicists

The fundamentals of wave propagation, optimization of the frequency translation path, different signal analysis techniques, and the benefits and trade-offs of each one
